Model:MVI56-MNETR
Brand:PROSOFT
Module Type:Ethernet Communication Module
Compatibility:Backward-compatible with previous MVI56-MNETR versions
Backplane Compatibility:Single-Slot ControlLogix backplane compatible
Data Transfer Speed:10/100 Mbps auto crossover detection
Configuration Port:Ethernet configuration and application port
Memory Mapping:User definable module data memory mapping of up to 5000, 16-bit registers
Diagnostic Capabilities:CIPconnect-enabled network configuration and diagnostics monitoring using ControlLogix 1756-ENxT and 1756-CNB modules
I/O Image Size:Reduced I/O image size designed specifically to optimize remote rack implementations
The PROSOFT MVI56-MNETR is a high-performance Ethernet communication module designed for seamless integration with Allen-Bradley ControlLogix systems. Its key feature is the ability to provide efficient data transfer and network configuration, making it an indispensable component for industrial automation processes. This module supports 10/100 Mbps auto crossover detection Ethernet, ensuring reliable communication even in challenging environments. With backward compatibility to previous versions, the MVI56-MNETR can easily integrate into existing systems without requiring significant modifications.
The module’s user-definable memory mapping allows for up to 5000, 16-bit registers, providing flexibility in configuring the system according to specific needs. The integrated diagnostic monitoring capabilities through CIPconnect-enabled network configuration and diagnostics monitoring using ControlLogix 1756-ENxT and 1756-CNB modules enable real-time monitoring and troubleshooting, enhancing system reliability and uptime.
Furthermore, the MVI56-MNETR supports EtherNet/IP pass-through communication, which simplifies network architecture by allowing multiple devices to communicate over a single connection. The reduced I/O image size is specifically designed to optimize remote rack implementations, making it ideal for distributed control systems.
With the ProSoft Configuration Builder (PCB) software, users can easily configure and manage the module, ensuring optimal performance and ease of use. Overall, the PROSOFT MVI56-MNETR is a powerful solution for enhancing the efficiency and reliability of industrial automation processes.
