Module Type:Process Control Loop Module
Compatibility:Compatible with HP 5000 series controllers
Input Range:0-20mA, 4-20mA, 0-5V, 0-10V
Response Time:≤50ms
Operating Voltage:24V DC
Operating Temperature:-20°C to +60°C
Protection Rating:IP65
Communication Protocol:RS-485, Modbus/RTU
Size:80mm x 100mm x 30mm
Weight:0.3kg
The HP 58503A Precision Oscilloscope Module is designed to meet the stringent demands of modern electronics testing. With its exceptional accuracy and real-time sampling capabilities, it ensures reliable measurements for complex signals. The oscilloscope features four fully isolated channels, allowing simultaneous observation of multiple signals without compromising measurement integrity. Its high-resolution display presents clear and detailed waveforms, making it ideal for intricate analysis tasks. Furthermore, the module supports various trigger modes including edge, pulse, video, and pattern triggers, providing versatile signal acquisition options. The inclusion of interfaces like GPIB, LAN, and USB enables seamless integration with other laboratory equipment and automation systems, enhancing overall efficiency. Crafted with robust materials, this module delivers consistent performance under demanding conditions, ensuring long-term reliability and durability.
