Output Voltage (+5V):5 Volts
Output Voltage (-15V):±15 Volts
Module Housing Material:Metal
Input Voltage Range:AC Input Module
Power Rating:High Capacity
Monitoring Capabilities:Flame Loss, Fire, Vibration
Maintenance Support:GE-Provided Technical Assistance
The GE DS3820PSCB1C1B is an essential part of the GE Mark IV series, specifically tailored for turbine control systems in gas and steam turbines. This power supply is meticulously engineered to streamline operational efficiency and ensure safety, thanks to its advanced automation capabilities and comprehensive monitoring functions.
Equipped with a robust metal housing, the DS3820PSCB1C1B incorporates multiple DS3800 PCBs alongside additional components such as capacitors of various materials, potentiometers, thermistors, amplifiers, transistors, and spare PTH, all contributing to its reliability and performance.
The design highlights include a 4-pin female jack for easy connectivity, a fuse for surge protection, and a circuit that ensures seamless operation within the turbine control system. A collar clamp reinforces the overall structure, enhancing stability and durability.
With a rating of +5V and +/-15V, this power supply is capable of providing the precise voltage needed for optimal functioning in turbine environments. Its versatile compatibility with different components makes it a preferred choice among engineers and maintenance teams.
Tech support for the DS3820PSCB1C1B is backed by GE, ensuring that users have access to expert assistance throughout their product lifecycle. This commitment to customer satisfaction further solidifies the DS3820PSCB1C1B’s position as a reliable and indispensable component in industrial turbine control systems.
