Emerson KJ3202X1-BA1 High Side Output Module

Type:High Side Output Module

Model:KJ3202X1-BA1

Brand:EMERSON

Series:DeltaV

Output Current:20A

Rated Voltage:DC 24V

Response Time:≤ 2ms

Operating Temperature:-40°C to +85°C

Mounting Style:Panel Mount

Connection Type:Terminal Block

Communication Protocol:Modbus RTU

Input Type:Digital

Load Capacity:Up to 16A at 24V DC

Enclosure Type:IP20

Power Consumption:≤ 0.5W

Dimensions:86mm x 90mm x 105mm

Weight:0.2kg

    The EMERSON KJ3202X1-BA1 High Side Output Module is a robust solution for high-demand industrial environments. Designed for seamless integration into DeltaV systems, it ensures stable current control under all operational conditions.

    Featuring an advanced microcontroller architecture, this module offers enhanced reliability and efficiency. Its high-side output capability supports a wide range of loads, making it suitable for various applications in manufacturing, process control, and automation.

    With a temperature range of -40°C to +85°C, this module is engineered to withstand extreme environmental conditions, ensuring continuous performance in challenging industrial settings. Its compact size and lightweight design facilitate easy installation and maintenance.

    Equipped with a variety of safety certifications including UL, CE, and EN50155, the EMERSON KJ3202X1-BA1 complies with international standards for electrical safety and reliability. This guarantees optimal performance and safety across diverse industries.

    The M8 x 0.8mm² connection type ensures secure and reliable data transmission, while the high-quality materials used in its construction provide durability and resistance to wear and tear. This module is the perfect choice for enhancing the precision and reliability of your industrial control systems.
