Allen-Bradley 1769-ECR A Source Output Module, High Performance Automation Solution

Product Type:PLC Output Module

Model Number:1769-ECR-A

Manufacturer:Allen-Bradley

Operating Altitude:Up to 2000 meters (6562 feet)

Bus Current Draw:5 mA at 5 volts DC

Backplane Current:1.4 Amps at 24 volts

Power Consumption:33.6 Watts

Weight:130 g (0.286 lb)

Enclosure Style:Open

Installation Position:Right end of the CompactLogix assembly

Module Compatibility:CompactLogix product family

    Engineered for seamless integration into the CompactLogix PLC ecosystem, the Allen-Bradley 1769-ECR Source Output Module ensures high-performance control outputs directly at the system’s end, optimizing efficiency and reducing cable connections for streamlined installations.

    This module boasts a compact design with a lightweight enclosure, weighing just 130 grams, which makes it highly portable and easy to install in various industrial settings without compromising on functionality.

    Featuring a maximum bus current draw of 5 milliamps at 5 volts DC, it is perfectly suited for applications requiring precise control over actuators, solenoids, or other low-power devices.

    With its robust design and compatibility with the Allen-Bradley PLC system, the 1769-ECR Source Output Module supports diverse industrial applications, enhancing system reliability and minimizing downtime.

    Ideal for manufacturers seeking to enhance their production line automation capabilities, this output module is an essential component for achieving precision and efficiency in manufacturing processes, contributing to overall productivity gains.
