Manufacturer:ABB
Model:AX645 3BHB001914R1
Module Type:Analog I/O
Dimensions (WxHxD):22.5 x 140 x 105 mm
Weight:0.6 kg
Operating Voltage:DC 24V
Current Consumption:≤50 mA
Input Signal Range:-10V to +10V
Output Signal Range:0V to 10V or 4mA to 20mA
Operating Temperature:-25°C to +70°C
Storage Temperature:-40°C to +85°C
Connectors:16-pin DIN Rail Mounting
IP Rating:IP20
Number of Channels:8 Input / 8 Output
Communication Protocol:Modbus RTU
Operating Frequency:50/60 Hz
The ABB AX645 3BHB001914R1 Analog I/O Module is engineered to enhance the performance of industrial automation systems, delivering exceptional accuracy and reliability in real-time control scenarios. Its compact design ensures seamless integration into diverse industrial settings.
Equipped with a wide operating voltage range, this module supports a broad spectrum of power supplies, ensuring compatibility across various applications. The robust input and output current ranges allow for precise signal processing and response times as low as 1 millisecond, making it ideal for demanding control tasks.
Operating within an extensive temperature range from -25°C to +60°C, this module maintains stable performance under varying environmental conditions. Its storage capability extends beyond operational limits, providing durability during transportation or storage.
With its lightweight design, the ABB AX645 3BHB001914R1 is highly portable and easy to install, minimizing setup time and reducing installation costs. The module’s compact size and efficient performance make it a preferred choice for space-constrained industrial environments.
Designed for maximum versatility, this Analog I/O Module from ABB offers compatibility with a wide array of control systems, enhancing system interoperability and streamlining integration processes. Its precision and reliability are further bolstered by ABB’s commitment to quality, ensuring long-lasting performance in critical applications.
