Operating Voltage:24V DC
Current Rating:2A
Switching Frequency:Up to 2 kHz
Relay Type:SPDT (Single Pole Double Throw)
Contact Rating:2000V AC/1000V DC
Temperature Range:-25°C to +60°C
Environmental Protection:IP20 (Front Panel)
Dimensions:84mm x 51mm x 24mm
Weight:Approximately 40g
The ABB DSQC563 Brake Release Board offers precise control over brake release mechanisms in industrial settings, ensuring smooth operation and reduced downtime. Its robust design withstands harsh environmental conditions, making it suitable for various manufacturing environments.
Equipped with advanced circuitry, this board ensures reliable switching performance even under high-frequency switching conditions, critical for applications requiring fast response times. The high current capacity allows for efficient power handling, supporting the release of heavy-duty brakes.
With an operating voltage of 24 VDC, the DSQC563 is compatible with a wide range of automation systems, providing flexibility in integration. The temperature range from -25°C to +70°C ensures continuous performance across diverse climates, further enhancing its applicability in global industrial setups.
Certified to meet international safety standards including CE and UL, the DSQC563 provides peace of mind, ensuring compliance with industry regulations. The PCB mounting type facilitates easy installation and integration into existing control panels, streamlining the setup process.
This product is a testament to ABB’s commitment to innovation and reliability in industrial automation. It represents a significant upgrade in brake control capabilities, offering enhanced safety measures and operational efficiency for manufacturers seeking to optimize their production lines.
