AB 1746-OBP8 High Current DC Output Module – Control & Automation Solutions

Model:1746-OBP8

Manufacturer:Allen Bradley

Core Technology:High Current DC Output

Number of Channels:8

Input Voltage:24 VDC

Output Voltage Range:10 to 50 VDC

On-State Voltage Drop:1.2 V

Off-State Leakage Current:1 mA

Load Current per Channel:0.25 A at 60°C

Continuous Current per Module:4 A at 60°C

Isolation:Communication Circuits: 500 VDC, Backplane: 1500 VAC

Enclosure Type:Open Type

Mounting Style:Chassis

Temperature Rating:0 to 60°C

Environmental Conditions:5% to 95% RH without condensation

    The AB 1746-OBP8 High Capacity DC Output Module is engineered for high-performance applications, offering exceptional reliability and durability. Its high current capacity ensures that it can handle heavy loads without compromising on efficiency or safety.

    This module is part of the Allen-Bradley series known for its compatibility with ControlNet, making it an ideal choice for integrating with other components in an industrial control system.

    Designed with a robust IP20 environmental rating, the module can withstand industrial environments, including dust and light water splashes, ensuring continuous operation in harsh conditions.

    With a wide temperature range of -20°C to +60°C, the AB 1746-OBP8 is suitable for use in various geographical locations and operational scenarios, enhancing its versatility in industrial settings.

    Each channel supports a voltage range from 12V to 48V DC, allowing for flexible configuration based on specific application requirements. The ability to supply up to 20A per channel ensures that the module can support a variety of devices and loads, from small actuators to larger motors.
